Instrumentation & Control Cables Manufactured as per BS:5308/IS:1554/EN:50228
Screens (Shields) are often used in Instrumentation and signal cables to prevent or decrease possible interference/ noise in cables that can be caused by following reasons:
Cross-talk from adjacent pairs or triads
Interference induced by external source such as electrical equipment's machineries and powerlines.
SCREEN TYPES
Aluminum/ polyester tape with a tinned copper drain wire, the most common construction
Copper/ polyester tape with a tinned copper drain wire, for a superior screen effect.
Bare copper braid, for electromagnetic interference/ noise or when the cable is subject to movements.
Tinned copper braid for electromagnetic interference in existence of corrosive atmosphere.
Enquiry form
PVC/PVC OVERALL SCREENED INSTRUMENT CABLE BS 5308 PART 2 : TYPE 1 300/500V
CONSTRUCTION
Conductor: Plain annealed/tinned circular stranded copper conductor, conform to BS 6360 / IS:8130
Insulation: PVC (Polyvinyl Chloride) / PE
Pairing: Two insulated cores shall be uniformly twisted together to form a pair with maximum lay length of 100 mm. Note :Two pair cables with overall screen shall have four cores laid in quad formation.
Pair identification: Colour code as per Appendix B or as per customer specification
Cabling: Twisted pairs are laid up together, if necessary filled with nonhygroscopic material compatible with the insulation.
Overall Screening: Accumulated pairs screened with aluminium/mylar tape, helically applied with the metallic side down, in electrical contact with a tinned 2 annealed copper drain wire of 0.5 mm.
PVC/PVC INDIVIDUAL & OVERALL SCREENED INSTRUMENT CABLE BS 5308 PART 2 : TYPE 1 300/500V
CONSTRUCTION
Conductor: Plain annealed/tinned circular stranded copper conductor, conform to BS 6360 / IS:8130
Insulation: PVC (Polyvinyl Chloride) / PE
Pairing: Two insulated cores shall be uniformly twisted together to form a pair with maximum lay length of 100 mm. Note :Two pair cables with overall screen shall have four cores laid in quad formation.
Pair identification: Colour code as per Appendix B or as per customer specification.
Individual Screening: Each pair screened with aluminium/mylar tape, helically applied with the metallic side down, in electrical contact with a tinned annealed 2 copper drain wire of 0.5 mm .
Cabling: Twisted pairs are laid up together, if necessary filled with nonhygroscopic material compatible with the insulation
Overall Screening: Accumulated pairs screened with aluminium/mylar tape, helically applied with the metallic side down, in electrical contact with a tinned 2 annealed copper drain wire of 0.5 mm .
PVC/PVC/SWA/PVC OVERALL SCREENED INSTRUMENT CABLE BS 5308 PART 2 : TYPE 2 300/500V
CONSTRUCTION
Conductor: Plain annealed/tinned circular stranded copper conductor, conform to BS 6360 / IS:8130
Insulation: PVC (Polyvinyl Chloride) / PE
Pairing: Two insulated cores shall be uniformly twisted together to form a pair with maximum lay length of 100 mm. Note :Two pair cables with overall screen shall have four cores laid in quad formation.
Pair identification: Colour code as per Appendix B or as per customer specification
Cabling: Twisted pairs are laid up together, if necessary filled with nonhygroscopic material compatible with the insulation
Overall Screening: Accumulated pairs screened with aluminium/mylar tape, helically applied with the metallic side down, in electrical contact with a tinned 2 annealed copper drain wire of 0.5 mm.
Bedding: PVC (Polyvinyl Chloride).
Armouring: Galvanized steel round wire over the bedding.
PVC/PVC/SWA/PVC OVERALL SCREENED INSTRUMENT CABLE BS 5308 PART 2 : TYPE 2 300/500V
CONSTRUCTION
Conductor: Plain annealed/tinned circular stranded copper conductor, conform to BS 6360 / IS:8130
Insulation: PVC (Polyvinyl Chloride) / PE
Pairing: Two insulated cores shall be uniformly twisted together to form a pair with maximum lay length of 100 mm.
Pair identification: Colour code as per Appendix B or as per customer specification
Individual Screening: Each pair screened with aluminium/mylar tape, helically applied with the metallic side down, in electrical contact with a tinned annealed 2 copper drain wire of 0.5 mm.
Cabling: Twisted pairs are laid up together, if necessary filled with nonhygroscopic material compatible with the insulation
Overall Screening: Accumulated pairs screened with aluminium/mylar tape, helically applied with the metallic side down, in electrical contact with a tinned 2 annealed copper drain wire of 0.5 mm.
Bedding: PVC (Polyvinyl Chloride).
Armouring: Galvanized steel round wire over the bedding.
